IP to CATV RF Digital QAM Gateway with MPEG-4 (H.264) to MPEG-2 transcoding - 64 Channels

Hermes 64 is an MPEG Transcoder integrated with a CATV RF Modulator for easy encoding, modulation and signal distribution. The most popular video encoding format in the world is H.264, due to its efficiency, and it is being used for IP and satellite video transmissions. However, the encoding standard used to transport video with CATV RF QAM or Off-Air modulation in the USA, Canada, and Mexico is actually MPEG2 Video with Dolby AC3 Audio. Most TV tuners purchased in those countries will not be able to decode RF signals carrying H.264. This is why the Hermes helps receive widely used H.264 IP streams, transcode them to the MPEG2 encoding format, and modulate them in J.32B QAM channels so that US, Canadian, and Mexican TVs will be able to display them, solving common distribution issues. The common application is receiving IP streams from satellite or IPTV providers through the satellite COM3000 gateway and converting them to the US MPEG2 standard. The transcoded bit rate can be adjusted form 1-19Mbps. After encoding and multiplexing, the device will modulate the signals into DVB-T/T2, DVB-C, ATSC, and ISDB standards. Thanks to its IP input port in the front panel, it can take in the IP signal and output in RF signal as well making a well rounded device to execute large scale applications.

• Up to 64 IP stream inputs
• Up to 32 QAM RF channel outputs
• H.264 streams are converted to MPEG-2
• Video encoding in H.264 and audio encoding in MPEG and AAC
• Supports all major resolutions from 480i to 1080p60
• CA PID filtering, remapping, and PSI/SI editing
• Offers 32 continuous RF output channels, with 2 programs muxed into each channel
• Easy configuration with built-in Web UI

H-HERMES-64 - IP to CATV RF Digital QAM Gateway with H.264 to MPEG2 transcoding option - 64 video streams modulated on 32 QAM channels
