HDMI over IP converters have been on the market for quite some time but their operation and use remain a mystery for many people. No wonder – it’s not easy to imagine that a small box can enable sending HDMI signal transmission over an IP network to a fairly considerable distance. Contrary to what may be generally believed, the operation and use of any type of converter is very straight forward and you should not be afraid of it. While highly sophisticated IPTV networks can require many hours to setup; simpler and smaller IPTV networks can be up and running in a short period of time.
Who should think about buying an HDMI over IP converter? Which devices can you connect to the converter?
You can connect many popular devices to the HDMI over IP converter: these usually include anything with an HDMI output like a satellite tuner, DVD player, computer, Blu-ray player, gaming console, camera and various types of monitoring devices used as a transmitter. Since many devices can use IP as a receiving signal, the HDMI over IP convertercan be useful at home or in small offices, industrial plants, hotels, conference centers, shopping malls, airports, university campuses, sports stadiums, casino's, and classrooms.
This Device is a 4 Channel HDMI Encoder that supports MPEG-2 H.264 & AC/3 with IPTV and ASI ouput. This Unit is a Real Time Encoder for 4 HDMI on ASI or IP with AC/3
Features
Real-Time MPEG-2/H.264 Encoder with Low Latency option
Independent control for encoding parameters on each channel
Supports Dolby AC/3 audio codec for compliance with US TVs
Designed to easily add 4 additional channels to a QAM-IP
Redundant hot standby power supply for highest reliability
Ip Stream Out: 1x MPTS and 4x SPTS over UDP, RTP/RTSP our (RJ45, 100M)
Digital modulator for HD video distribution over coax - QAM, ATSC, DVB-T. Broadcast over the existing Coaxial Cabling to an unlimited number of Televisions with FULL HDBroadcast Live HDMI Video as Cable TV & IPTV Channels.
Features
Integrates fully independent encoders with a multiplexer and modulator
Modulates up to 4 adjacent QAM-256 carriers with up to 38 Mbps each
Supports full HD 1080p60 input & encoding from any HDMI digital video source
Each encoder independently configured: supports all standard HDTV resolutions
IPTV output on second network port in UDP IGMP Multicast or Unicast format
DVB-ASI output on mirrored BNC terminals for use in broadcasting systems
Fully network managed device with all settings configurable through web browser
Conversions : HDMI to RF, HDMI to IP, HDMI to ASI
Any 1-4 HDMI Input up to 720p/1080i/1080p60
Licensed HDMI inputs
1-4 CATV RF Output up to 4 Adjacent channels
QAM-256/64
Fully IP control and Network Management through browser
Front Panel LCD local control
IPTV Output Unicast or Multicast IGMP UDP, RTP/RTSP
ASI Output with multiplexer cherry picking
Low Latency available 70-120ms
AC3 Audio available (AC3 model)
MPEG2 Video or MPEG4 H.264 Encoding
Firmware for ATSC, DVB-T, DVB-S2 Available
2 slot design – Other Video Inputs cards available –Hot swappable - SDI Card, YpbPr Card.
This Unit Generates ATSC TV channel form any DVD player or STB or computer HDMI HDCP source. You can Broadcast up to 4 any HDMI Video North American ATSC Antenna & IPTV Channels.
Features
ATSC 8VSB 19Mbps RF Output up to 4 Out
IPTV Output Unicast or Multicast IGMP UDP, RTP/RTSP
ASI Output with multiplexer cherry picking
Any HDMI Input up to 1.5A @1080p60
ASI Input SPTS or MPTS up to 120 Mbps
Fully Network Managed through browser
Integrates fully independent encoders with a multiplexer and modulator
Modulates up to 4 adjacent 8VSB carriers compatible with ATSC format
Supports full HD 1080p60 input & encoding from any HDMI digital video source
Each encoder independently configured: supports all standard HDTV resolutions
IPTV output on second network port in UDP IGMP Multicast or Unicast format
DVB-ASI output on mirrored BNC terminals for use in broadcasting systems
Fully network managed device with all settings configurable through web browser
Convert HD video signals to full HD digital DVB-T television channels for display on any TV. Broadcast over your existing Coaxial Cabling to an unlimited number of Televisions with FULL HD
Features
Conversions : HDMI to RF DVB-T , HDMI to IP, HDMI to ASI
Any 1-4 HDMI Input up to 720p/1080i/1080p60
Licensed HDMI inputs
1-4 CATV RF Output up to 4 Adjacent channels
QPSK QAM-16/26 RF Out up to 4 Adjacent
Fully IP control and Network Management through browser
Front Panel LCD local control
IPTV Output Unicast or Multicast IGMP UDP,RTP/RTSP
ASI Output with multiplexer cherry picking
Low Latency available 70-120ms
AC3 Audio available (AC3 model)
MPEG2 Video or MPEG4 H.264 Encoding
Firmware for ATSC, DVB-T, DVB-S2 Available
2 slot design – Other Video Inputs cards available –Hot swappable - SDI Card, YpbPr Card.
5 Years warranty
Any HDMI Input up to Full HD @1080p60
ASI Input SPTS or MPTS up to 120 Mbps
Integrates fully independent encoders with a multiplexer and modulator
Modulates up to 4 adjacent QPSK, QAM-16/64 carriers with up to 28 Mbps each
Supports full HD 1080p60 input & encoding from any HDMI digital video source
Each encoder independently configured: supports all standard HDTV resolutions
IPTV output on second network port in UDP IGMP Multicast or Unicast format
DVB-ASI output on mirrored BNC terminals for use in broadcasting systems
Fully network managed device with all settings configurable through web browser
This RF Modulator has 4 HDMi inputs and Closed Caption. The platform provides 5 full RF carrier outputs for generating channels from content ingested through the ASI input. Encoding in either MPEG2 or H.264 is provided for 4 crystal clear video streams up to 1080p 60 each HDMI to coax , HDMI to IPTV ,HDMI over coax
Features
Broadcast over existing Coaxial Cabling to an unlimited number of Televisions with FULL HD
Perfect for Professional Stadiums and Arena's
#1 in Live Sports and Entertainment
Broadcast Live HDMI & YPbPr Video as Cable TV & IPTV Channels.
Licensed HDMI inputs - works with any source like DVD, Blu-Ray, or any STB
Convert HDMI & Component YPbPr HD Video to HDTV Channels
Any 1-4 HDMI & YPbPr Inputs up to 720p / 1080i / 1080p
Licensed HDMI inputs - works with any source like DVD, Blu-Ray, or any STB
Thor Broadcast CMOD series compact encoder modulator with support for the Dolby AC/3 audio codec. This model line provides support for legacy USA tuners requiring the AC/3 audio codec for proper decoding.
Features
Dual HD or SD channels in compact encoder modulator form factor
Supports both MPEG-2 or H.264 video encoding codecs
Supports Dolby AC/3 audio passthrough up 7.1 channels
Models available for ATSC, DVB-C, or DVB-T Television (unit comes loaded with QAM & ATSC modulation standards)
Supports IPTV output in UDP format for unicast or multicast
Supports EIA 608 type closed captioning on analog input
ASI input and multiplexing function provided with ASI output
This Device will Live Broadcast any HDMI source. This Unit is a Single Channel Encoder Streamer with multiple input options to stream any HDMI input into an MPEG 4 stream that is web managed and can be viewed over LAN or Public Internet RTSP/HTTP Encoder streamer. This Unit Transports HD/SD HDMI video as UDP(unicast or multicast), RTP/RTSP, HTTP, HLS.
Features
Convert HDMI HD Video to an IP stream
One Input from HDMI
Licensed HDMI input
MPEG4 // AVC-H.264
Full IP control and Network Management through browser
This Unit has 2 HDMI and 2 SDI inputs with RF CATV QAM and ATSC output. You can Broadcast over existing Coaxial Cabling to an unlimited number of Televisions in FULL HD
Features
Convert 2 HDMI & 2 SDI HD Video Content programs to Perfect QAM Channels simultaneously
Any 2 HDMI & 2 SDI Inputs up to 720p/1080i/1080p
Licensed HDMI inputs
2 HDMI and 2 BNC cables FREE
Support DD AC3 (2.0/5.1/7.1) passthrough(for HDMI interface only)
Support CC (Closed Caption) EIA608,and EIA708 on SDI’s
1-4 CATV RF Output up to 4 Adjacent channels
QAM-256/64, DVB-T, & ATSC formats available
Fully IP control and Network Management through browser
Front Panel LCD local control
IPTV Output Unicast or Multicast IGMP UDP/RTP/RTSP
ASI Output with multiplexer cherry picking
Low Latency available 70-120ms mode
Dolby AC3 Audio encoding and Doby AC3, 5.1 Pass-Trough
MPEG2 Video or MPEG4 H.264 Encoding
Firmware for DVB-C, ATSC, DVB-T, DVB-S2, ISDB-T Available
VCT (Virtual Channel Table) support—for DVB-C ATSC and DVB-T
This Device is used to encode HD Video from HDMI source to MPEG 4 / H.264 and stream over public internet using following IPTV protocols: M3U8, HLS, HTTP, RTMP, RTSP
Features
HDMI HDCP Inputs
MPEG-4 AVC/H.264 video encoding and LC-AAC or HE-AAC Audio encoding
IP Output over UDP (Unicast/Multicast), RTSP, RTMP, HTTP and HLS
Built-In Simultaneous IPTV Streaming Server,
Logo, Caption, QR Code inserting
Control and easy updates via web management NMS GUI
Four Scalers and Multi-Rate per each
APLICATIONS:
LIVE HDMI Video UDP /RTP distribution over the existing IP LAN Networks to an unlimited number of TV & IPTV Players
Direct streaming To SmartTVs
Direct streaming To Any IP Box
Direct streaming To Iphones Ipads Galaxy Android
Direct streaming To PCs
Direct streaming To WAN Internet
Direct streaming To YouTube
Direct straming To FaceBook,
Direct streaming To SmartTVs
Check the technical specifications of your devices
If you want to avoid unpleasant surprises, you should compare the technical specifications of your devices and converters. Check which converter models are compatible with your devices and then select the converter that best suits your needs. Here is the list of the most important technical specifications you should pay attention to: Supported video formats: the quality of the video depends on the type of the supported video format. Nowadays, the standard resolution supported by most of the devices is 1080i and 1080p (and lower, of course), although more and more often you can also find converters that support 4k resolution, also known as Ultra High Definition.
Manufacturers of converters definitely keep pace with the development of modern technologies. Maximum transmission range: different manufacturers offer different maximum transmission ranges. Most converters on the market give you various ranges of extending the HDMI signal transmission up to 100 meters, although you can also find cables which are even 120 meters long. Check the distance between the installation start and end points.
Don’t forget to check whether the converter can send the HDMI signal only for short distances (e.g. 2 m, 10 m), or if it is equipped with an extender that allows HDMI signal transmission over long distances (e.g. 100 m). Operating temperature and humidity: if you plan to install the converter at home, you will probably comply with the requirements specified by the manufacturer. However, if the transmitter or receiver is located in an unheated guard booth, the devices may not work properly at low temperatures. Types of cables and twisted pair cables: check the compatibility of the required cables and twisted pair cables with the inputs and outputs of your devices.
Check what video and audio cables other than HDMI may be needed to connect your devices to the converter. Do not forget to check whether the converter requires computer twisted cat5e or cat6. In most cases, both types of twisted pair cables are compatible with the model you would like to buy. Compare prices of converters from different brands Use online price comparison websites in order to check the prices of converters offered by different manufacturers. You can, of course, check the official websites of manufacturers or shops with converters, however, it requires much more time and there is a big chance that you will miss a discount of the store which is not listed on the first page of the search engine results if you look for “HDMI over IP converter”. Also take into account warranty and tech support, but always make sure to verify compatibility and functionality for your infrastructure first.
Remember, however, that you should not only care about the price of the converter: the most expensive converter is not always the best. On the other hand, the reasonably priced product can be a very basic version of the converter, e.g. without an extender or cables. Don’t forget to check the Internet reviews of people who bought the HDMI over IP converters.
Check what is included in the set As mentioned above, some manufacturers of HDMI over IP converters tempt us with affordable prices but do not offer a well-equipped set, or functional equipment. Check whether the manufacturer includes the necessary cables, or if you need to buy them on your own. Check if the set includes only a transmitter or only a receiver, or maybe the manufacturer offers both devices or even an additional receiver. In most cases you only need a converter because you'll be using existing pieces to decode the IP stream.
Check compatible cables, accessories and devices
Some converters’ manufacturers or sellers help their clients by listing on their website the compatible cables, accessories and devices for each converter model. It is worth paying attention to those converters that have a wide range of compatible products. Who knows, you will also need emulator, switch, adapter, splitter or another device to help facilitate your IP link?
