Thor Broadcast IP Encoder with 4 or 8 HDMI inputs with MPEG-4 AVC/H.264 video encoding and LC-AAC or HE-AAC audio encoding. The signal source could be from any STB, PC, TV, or any HDMI device. It can transfer the livestreaming programs through the internet via LAN, and will output IP over UDP (Unicast/Multicast), RTSP, RTMP, HTTP and HLS, and the output signals can be received by an IP device like a PC, phone, tablet, STB or any other mobile terminals. Simple setup and design means these inexpensive units will give you video IP transports solutions without breaking the bank.
Models are available with 4, 8 HDMI inputs for high density applications
You can use it as a live video or move cast streaming device and have the versilitiy to connect with a large audience. This unit supports multiple HD and SD resolutions; if your video source is Analog NTSC video, it is easy to convert it to HDMI using small external converter.
APLICATIONS:
LIVE HDMI Video UDP /RTP distribution over the existing IP LAN Networks to an unlimited number of TV & IPTV Players
Direct streaming To SmartTVs
Direct streaming To Any IP Box
Direct streaming To Iphones Ipads Galaxy Android
Direct streaming To PCs
Direct streaming To WAN Internet
Direct streaming To YouTube
Direct straming To FaceBook,
Direct streaming To SmartTVs
H-4HDMI-IPCast - Four HDMI to IP streaming server
H-8HDMI-IPCast - Eight HDMI to IP streaming server
|
Input |
HDMI inputs |
|||
|
Encoder Section |
Video |
Resolution |
Input |
Output |
|
1920x1080_60p, 1920x1080_60i |
1920x1080_30p |
|||
|
1920x1080_50p, 1920x1080_50i |
1920x1080_25p |
|||
|
1280x720_60p |
1280x720_30p |
|||
|
1280x720_50p |
1280x720_25p |
|||
|
720x480_60i |
720x480_30p |
|||
|
720x576_50i |
720x576_25p |
|||
|
Bit rate |
1Mbps~13Mbps |
|||
|
Rate Mode |
CBR, VBR |
|||
|
GOP Size |
25~50 |
|||
|
Audio |
Encoding |
LC-AAC or HE-AAC |
||
|
Sampling rate |
44.1KHz |
|||
|
Bitrate |
LC-AAC : 48, 64, 96, 128, 256 kbps HE-AAC : 48, 64 kbps |
|||
|
Stream out |
IP out over UDP (Unicast/Multicast) , RTSP, RTMP, HTTP, HLS (RJ45, 100M ) |
|||
|
System |
Remote control |
Network management (WEB) |
||
|
Language |
English |
|||
|
Upgrade |
Ethernet software upgrade |
|||
|
General |
Operation temperature |
0~45°c(work), -20~80°c(Storage) |
||
|
Power supply |
AC 100-240V 50/60Hz 2A |
|||
|
Dimensions |
482mm×328mm×44mm |
|||
We only have a few options for HLS encoding; this model is the best option; we only have the 8 Channels in stock right now.
HLS Syntex for IPCAST unit is http://192.168.1.137:8090/stream1.m4u8 , the 192.168.1.137 is the default device IP address
Low Cost Mini Dual HDMI IP Encoder H.264 Streamer - RTSP/RTMP/HTTP/HLS/UDP/RTP/SRT
The DUO MAGNI is designed to convert the 2 unique HDMI signals to IP SPTS with H.264 encoding.
Mini SD/HD/3D SDI Encoder streamer - UDP unicast/multicast, RTMP, HTTP, ONVIF, RTP, HLS, SRT
Thor NetLink Mini SDI is a simple solution for an SDI IPTV H.264/H.265 encoder-streamer for LAN and WAN. It is designed for video streaming, live broadcasting, tele-education, telemedicine, etc. It supports UDP unicast/multicast, RTMP, HTTP, ONVIF, RTP, HLS, SRT transmission, and point-to-point as well as point to multi-point transmission.
