Thor HDMI to Coax HD Channel Modulator to distribute your HDMI Video to TV's over coax as HDTV Channel

Perfect HD up to 1080P/60  HDMI to Coax RF DIGITAL MODULATOR, Network - Ethernet Control

The most unique and cost-effective Networked Digital HDMI RF modulator. Designed to allow any HDMI source like an STB, satellite receiver, HDMI camera, DVD player, Computer, and a ROKU device.You can convert to any RF TV channel of your choice.

This Thor Modulator is an all-in-one device integrating  HD MPEG2 encoding with AC3 Dolby Audio with an internal digital modulator. Converts HD audio/video signals from any device into DVB-C/T/ATSC/ISDB-T RF output.
The unit supports any HD source with the following video resolutions: 720p, 1080i, 1080p

Simply connect to any PC and control the unit via Thor Broadcast's proprietary GUI which has been touted as being the best on the market.

This unit is plug and play and has exceptional quality for a very low price to help anyone with any budget create their very own RF channel which can be viewed on thousands of televisions simultaneously.

• HDMI Input - HDCP compliant ( works with any HDMI device )
• 10/100 Ethernet NMS port for control, setup, and monitoring
• RF output could be set to any CATV format as QAM, ATSC, DVB-T, or ISDB-T
• RF output power is +24dbmv; enough for distributing HDTV video to 100's TV over existing coax cable network
• RF power could be controlled over the network via NMS Gui (Proprietary)
• MPEG2 video encoding
• AC3 Audio encoding
• Video bit rate 1-19.5Mbps can managed over the network
• Supports any CATV RF agile channels form 57-1000Mhz, channels  2 -135,
•  Supports output resolutions up to 1080p
•  Easy to set up via NMS.
•  Small size and light weight
• Includes wall-mount type rack ears
•  Install multiple units onto your TV system

NMS Video instruction describes how to connect and control the H-HDMI-RF-PETIT via your PC over IP Ethernet Network

This is a link to detailed PDF instructions: H-HDMI-RF-PETIT NMS Connection Instructions
