| Availability: | In stock | Condition: | new |
|
| Shipping: | starting at $0.00 | Warranty: | 1Yrs |
The F-MININODE is an HFC return path transmitter and RF optical receiver for use in fiber-to-the-home applications. The unit has 45-1000MHz RF outputs for digital TV as well as an optional optical transmitter for the 5-45MHz cable modem return path. We carry two-fiber units as well as WDM single-fiber units. The F-MININODE has many applications in Hybrid Fiber Coax systems and for fiber-to-the-home applications. This is a compact and highly reliable unit for use with analog, digital video, and bi-directional data transmission in HFC networks.
Thor has a dedicated team for FTTx applications. Every fiber optic cable system is different. We can provide a wide variety of OLT and ONU units to meet your FTTx and GPON needs. Contact a sales engineer today for help in determining what equipment is needed for your fiber optic system.
- Excellent linearity and flatness
- Extremely good return loss
- Compact construction, lower power consumption
- WDM option to achieve single-fiber bi-directional transmission
- Multi-communication transmitting wavelength and power optional
IMPORTANT NOTE*** (It is very important to interface our unit with SC/APC - Angle Polished Connector to avoid any light reflections.)
If your fiber is terminated with the SC, ST, FC /PC flat connector, you need to use an optical jumper from PC type to SC/APC for proper conversion.
• F-MININODE-1RT Receiver and Return Path Transmitter over single fiber
• F-MININODE-2RT Receiver and Return Path Transmitter over 2 fibers
|
Downstream |
|||||
|
Optical Receiver |
|||||
|
Wavelength Range |
nm |
1200 to 1620 |
|||
|
Input Power |
dBm |
-6 to +2 |
|||
|
Connector |
- - |
SC / APC IMPORTANT NOTE*** (It is very important to interface our unit with SC/APC - Angle Polished Connector to avoid any light reflections.) If your fiber is terminated with the SC, ST, FC /PC flat connector, you need to use an optical jumper from PC type to SC/APC for proper conversion. |
|||
|
Return Loss |
dB |
>= 55 with UPC type connector, >= 60 with APC type connector
|
|||
|
RF Performance |
|||||
|
Passband |
MHz |
54 to 1002, 70 to 1002, 85 to 1002 |
|||
|
Output Level |
- - |
21 dBmV @ -1 dBm optical input, 80 NTSC channels and 450 MHz digital loading, -6 dB relative to analog loading |
|||
|
CNR2 |
dBc |
>= 51 @ -1 dBm optical input |
|||
|
CSO |
dBc |
<= -65 @ -1 dBm optical input |
|||
|
CTB |
dBc |
<= -67 @ -1 dBm optical input |
|||
|
Impedance |
Ohm |
75 |
|||
|
Output Return Loss |
dB |
>= 16 |
|||
|
Flatness |
dB |
+/- 1 |
|||
|
Upstream |
|||||
|
Return Transmitter |
|||||
|
Center Wavelength |
nm |
1310 |
|||
|
Output Power |
dBm |
FP: 0, DFB: +3, CWDM: +3 |
|||
|
Connector |
- - |
SC / APC - standard1 |
|||
|
Return Loss |
dB |
>= 55 with UPC type connector, >= 60 with APC type connector |
|||
|
RF Performance |
|||||
|
Passband |
MHz |
5 to 42, 5 to 55, 5 to 65 |
|||
|
Input Level |
dBmV / channel |
20 |
|||
|
Input Return Loss |
dB |
>= 16 |
|||
|
RF Gain Flatness |
dB |
+/- 1.5 |
|||
|
Return Path Frequency Range |
MHz |
5 to 42, 5 to 55, 5 to 65 |
|||
|
RF Gain Flatness |
dB |
+/- 1.5 |
|||
|
Link Performance |
|
FP Laser 2 |
DFB Laser 3 |
CWDM |
|
|
CNR2 |
dBc | >= 48 | >= 51 |
>= 51 |
|
|
CSO |
dBc |
<= -55 | <= -60 |
<= -60 |
|
|
DTO |
dBc |
<= -55 | <= -60 |
<= -60 |
|
|
General |
|||||
|
Test Points (All) |
dB |
-20 dB Forward Output,
-20 dB Return Input |
|||
|
Power |
VDC / mA |
15 / 600, F-type connector AC / DC power adapter to dedicated PWR input or RF output port with power inserter |
|||
|
Surge Withstand |
-- |
IEEE C62.41-1991 Cat. A3 (6 KV) for all ports |
|||
|
F Ports |
-- |
Conforms to SCTE 01 2006, sealed to hold 15 psi |
|||
|
Operating Temperature |
deg C ( deg F) |
-40 to +65 (-40 to +149) ambient |
|||
|
Humidity |
% |
up to 95, non-condensing |
|||
|
Dimensions (W x H x D) |
mm (in) |
152 x 91 x 33 (6 x 3.6 x 1.3) |
|||
|
Weight |
g (oz) |
396 (14) |
|||
