2 pcs L-mounting brackets, hardware, and screws.
Each bracket needs to be installed to enable mounting up to 12 individual modulators (H-HDMI-RF-PETTIT) onto horizontal bars for a 19" rack
With the Modulator Rack, you get all the great features you love about the Petit bundled together in groups from 2-12 Petits. This is perfect for CATV modulation applications in bars, restaurants and any other place that needs up to 12 different HDMI signals modulated throughout their facility.
When you order a Thor Chassis System with any amount of modulators, you will get the horizontal rack bars, and enough rack ears for the amount of units purchased in your set. You just need to attached the horizontal bars to your 1RU Rack, followed by adding the rack ears to each Petit, and then using screws to fasten the Petit's into the horizontal bars. As with all of Thor Broadcast units, we will gladly handle presetting the units if you so wish, so once you add the units into the rack, plug in the power supplies, HDMI, and RF cables, you'll be ready to launch your RF system in no time.
H-LB-PETTIT - 2 pieces of L-brackets hardware needed to mount multiple H-HDMI-RF-PETTIT.
Each L-bracket needs to be mounted on each side of the modulator, then secured into the horizontal bars (H-RM-PETTIT).
All screws are included, 2 for the modulator and 2 for the horizontal bars
OTDR Optical Time Domain Reflectometer
Optical Time Domain Reflectometer (OTDR) an intelligent meter for Optical loss test in fiber optic cable,
Horizontal 19" Rack-Mount bars for mounting up to 12 H-HDMI-RF-PETIT HDMI Modulators
Horizontal 19" rack-mounting bars hardware; it can be used for mounting 1 to 12 individual H-HDMI-RF-PETTIT modulators in a standard 19" rack
