2-32 Audio Over Fiber - RCA Connector

F-8A-RCA-TX/RX
Qty: 0
Price: $ 898.00
Availability: In stock Condition: new
Shipping: starting at $22.00 Warranty: 2Yrs
Quantity:
add to basket
ask about product
send request
Description Features Drawings Model Selection Specification Documents Support
8 Audio Over Fiber model description
8 Channel RCA Audio over Fiber Extender sends 8 channels line level audios over one multi-mode or single-mode optical fiber.
Description

The Thor Fiber RCA audio over fiber units are able to send Line Level audio over fiber simply adne easily over long distances without using traditional copper wiring. The units vary in size based on the amount of audio's for transmit and receive, from a compact form factor that can be easily bolted down, up to a rackmount 1RU unit for easy acces in a rack. The kits are sold in pairs, transmitter and receiver; and can utilize both Singlemode or Multimode fiber. Using fiber allows the audio signals to be sent over a long distances without losing any quality in the audio signal. The kit is 24-bit digitally encoded broadcast quality audio over one multi-mode or single-mode optical fiber. The fiber optic transmitter and fiber optic receiver are typically used in applications for Rental, Staging, Concerts, Theater, Churches, Stadiums, Theme Parks, Broadcast/Studio, Intercom,  CCTV audio and Professional AV applications. Standard fiber connectors are ST/PC. Basic units support up to 20Km of single mode / 3000 multimode fiber. The front panel LED indicators make it known when hot swapping, or switching audio paths if they are already connected and ready to go.

Features
  • Completely digital fiber transmition platform
  • No configuration or any adjusting needed, user friendly design, plug and play
  • Audio to fiber converter
  • LED link lights for power and fiber
  • No interference from adjacent power lines, sources or other
  • Completely digital, broadcast transmition
  • Power supplies included
  • Transmission distance up to 2 km Multimode & 20 km single mode (long haul available upon request
Drawings
Model Selection

F-2A-RCA-TX/RX  2 Audio fiber optic transmitter / receiver kit - 20Km single mode fiber , 3000 feet multimode fiber (portable form factor)

F-4A-RCA-TX/RX  4 Audio fiber optic transmitter / receiver kit - 20Km single mode fiber , 3000 feet multimode fiber (portable form factor)

F-8A-RCA-TX/RX  8 Audio fiber optic transmitter / receiver kit - 20Km single mode fiber , 3000 feet multimode fiber (portable form factor)

F-16A-RCA-TX/RX  16 Audio fiber optic transmitter / receiver kit - 20Km single mode fiber , 3000 feet multimode fiber (portable form factor)

F-32A-RCA-TX/RX  32 Audio fiber optic transmitter / receiver kit - 20Km single mode fiber , 3000 feet multimode fiber (portable form factor)



F-16A-RCA-TX/RX-RM  16 Audio fiber optic transmitter / receiver kit - 20Km single mode fiber , 3000 feet multimode fiber (19" Rack Mountable form factor)

F-32A-RCA-TX/RX-RM  32 Audio fiber optic transmitter / receiver kit - 20Km single mode fiber , 3000 feet multimode fiber (19" Rack Mountable form factor)

Specification
Wavelength 1310nm&1470nm~1610nm
Output Power -14~ -8dBm / -5~0dBm
Optic fiber 50/125u multimode, 62.5/125u multimode, 9/125u single mode
Rx sensitivity -30dBm
Optical connector ST/PC
Distance 0~2KM (MM)    /    0~20KM (SM)

Input/output Impedance 600ohm(unbalance)
Max input/output voltage 3.0Vp-p
Frequency Response 10 Hz~29kHz @±3dB
SNR > 70dB
Connector RCA

Input Power Requirements: DC 5V@2A
Power Adapter: AC 90V~240V
Power Consumption: < 5W
Stand-Alone Dimensions: 104mm × 104mm × 28mm
Shipping Weight: (include Transmitter & Receiver ) 0.8kg

Operating Temperature: -20°C ~ +75°C
Storage Temperature: -40°C ~ +85°C
Relative Humidity: 0% ~ 95% (non-condensing)
MTBF: >100,000 hours
